DEPG0420 series E-Paper (400×300) 4.2″
Product specs
| Weight | 16.1 g |
|---|---|
| Dimensions | 91.0 × 77.0 mm |
| Pixels | 400×300 |
| Interface | MCU, SPI |
Product Description
The DEPG0420 series is an Active Matrix Electrophoretic Display (AM EPD). The 4.2 inch active area contains 400×300 pixels. The module is a TFT-array driving electrophoresis display, with integrated circuits including gate driver, source driver, MCU & SPI interface, timing controller, oscillator, DC-DC, SRAM, LUT, VCOM.
This device is available in three different options: Black & White (B/W), Black, White & Yellow (B/W/Y) and Black, White & Red (B/W/R)
- 4.2″ E-Paper Display
- 400×300 Resolution
- Dimensions: 91.0mm x 77.0mm
- Active Area: 84.8mm x 63.6mm
- Pixel Size: 0.212mm x 0.212mm
- 120 DPI
- 175° Viewing Angles
- Available as (B/W), (B/W/Y) & (B/W/R)
