Geniatech XPI-3128 Single-Board Computer
Product Description
Geniatech’s XPI-3128 is a quad-core Cortex-A7 1.2GHz SOC that integrates a Mali-400MP2 GPU. It has excellent arithmetic and graphics processing capabilities,
providing high-performance video output and a smoothly high-resolution (1080p@60fps) display. It supports 2.4G/5GHz Wi-Fi, 802.11a/b/g/n/ac, and BT4.0.
It also has an onboard 100M Ethernet port and supports an external 40-pin interface, including UART, I2S, PCM, I2C, GPIO, and PWM, giving users a very flexible solution.
Geniatech’s XPI-3128 is a quad-core Cortex-A7 1.2GHz SOC that integrates a Mali-400MP2 GPU. It has excellent arithmetic and graphics processing capabilities,
providing high-performance video output and a smoothly high-resolution (1080p@60fps) display. It supports 2.4G/5GHz Wi-Fi, 802.11a/b/g/n/ac, and BT4.0.
It also has an onboard 100M Ethernet port and supports an external 40-pin interface, including UART, I2S, PCM, I2C, GPIO, and PWM, giving users a very flexible solution.
- 85mm*56mm, Only the size of a bank card
- Raspberry Pi Form Factor & GPIO Compatibility with RPI for Maximum Re-usability
- Rockchip RK3128 with Quad-core Cortex-A7 up to 1.2GHz
- 512MB/1G/2G RAM, 8GB/16G/32G/64G eMMc flash
- 4*USB HOST, 1*HDMI Out, 1*Type-C, 1*UART,
- 2.4&5.8G WiFi, BT4.0 and 100M LAN interface
- Raspberry Pi OS emulator, Linux(Debian 10/buildroot), Android
