NEW

HT32F52367 Starter Kit ESK32-30510

SKU: ESK32-30510 Categories: , , Manufacturer:

Product specs

Dimension:

100 x 66 x 11 (mm)

Net weight:

24.8g

Packing List:

HT32F52367 Starter Kit ESK32-30510 x 1

Product Description

The HT32F52367 Starter Kit uses the 32-bit Arm® Cortex®-M0+ high performance, low-power microcontroller, and is designed to help new users get up and running and using this Holtek device in the shortest possible time frame. It provides a low-cost platform which together with the software development platform, also provides a complete solution from evaluation, programming to production.

Characteristics

  1. Using HT32F52367 high performance, low-power microcontroller
    1. Up to 60MHz operating frequency
    2. 256KB Flash, 32KB SRAM
    3. Integrated multiple Timers, 2 I2C functions, 2 SPI functions, 2 USART functions, 4 UART functions, single 12-bit A/D converter, USB, I2S, QSPI and EBI function.
    4. Can be used for the testing and development of many external devices
    5. 80LQFP package
    6. 8.000 MHz External Crystal Clock
    7. 67 programmable general purpose I/O pins
  2. Comprises Target Board and Serial-Wire Debugger
  3. Can use the Target Board external power supply or be powered by the e-Link32 Pro USB supply



Development Environment

  1. Provides a standard C language program development environment
  2. Provides a comprehensive functional library avoiding much complicated lower level functional development
  3. Integrated hardware debug interface, SWD, connects to the IDE using a USB. The system will download the programs and debug immediately
  4. Provides a standard development environment, including Keil uVision and IAR EWARM
