REX006448A series 64×48 COG micro-OLED (0.66″)

SKU: REX006448A Categories: , , Manufacturer:
Download PDF

Product specs

Dimensions 18.46 × 18.1 mm
Pixels

64×48
Interface

6800, 8080, I2C, SPI
Construction

COG

Product Description

The REX006448A series is a Chip-On-Glass OLED offering 64×48 pixels, with an active area of 13.42mm x 10.06mm within a viewable area of 15.42mm x 12.06mm,  it comes with an integrated SSD1306 IC, and is available in Blue, White or Yellow.







  • 64×48 OLED
  • Available in Blue, White or Yellow
  • Dimensions: 18.46mm x 18.10mm
  • Viewing Area: 15.42mm x 12.06mm
  • SSD1306 IC on-board
  • Standard Operating Temperature of -40°C to +80°C
