Leaf Spring , 5.0mm Pitch , DG126R-5.0-xxP-1400AH
Product specs
| Pitch | 5mm |
|---|---|
| Poles | 2, 3 |
| Height | 7.8mm |
| Wire Orientation | Vertical |
| Clamp Type | Leaf Spring |
| Colour | Green |
Product Description
DG126R is a 90 Degree – Vertical wire insertion style leaf spring connector from Degson. Product is available in multiple poles and different colours upon request. Product is interlocking so any number of ways can be assembled by using a 2 & 3 way.
DG126R series is UL (E228872) approved.
- Pitch 5.0mm
- 90 Degree
- Leaf Spring
- 7.8mm High – 10.2mm Depth
- Ambient Temperature – -40 + 105C
- Housing – PA66
- Screw – M2.5 Combi
- UL File number E228872 – 14-26 Awg – 10A
