Rising Clamp , 15mm Pitch – DG137T-15.0-xxP-1400AH
Product specs
| Height | 39mm |
|---|---|
| Pitch | 15mm |
| Wire Orientation | Horizontal |
| Poles | 2, 3 |
| Clamp Type | Rising Clamp |
| Colour | Green |
Product Description
DG137T-15 series is Degsons largest pitch terminal blocks with four pins pin per pole for extra stability. Product is available in multiple poles but product is interlocking so any number of poles can be made up with a 2 & 3 way combination.
Dg128 series is both UL & VDE approved and with the highest V0 flammability rating.
- Pitch 15mm
- 39mm High – 31mm Depth
- Ambient Temperature – -40 + 105C
- Housing – PA66
- Screw – M5 slotted
- Torque – 20.4kgf / cm
- UL 4-35 Awg – 115A @ 600v
- VDE 2-20mm2 – 115A @ 1000v
- Interlocking device
- Colour Green as standard
