Leaf Spring , 5.0mm Pitch , DG300-5.0-xxP-1300AH
Product specs
| Height | 12.8mm |
|---|---|
| Pitch | 5mm |
| Wire Orientation | Horizontal |
| Poles | 2, 3, 4, 5, 6, 7, 8 |
| Clamp Type | Leaf Spring |
| Colour | Black |
Product Description
DG300-5.0 series is a 12.8mm high leaf spring connector from Degson. Product is available in multiple poles and different colours upon request. 5mm pitch product is interlocking so can be made up using any number of ways.
DG300 series is UL (E228872) approved.
- Pitch 5.0mm
- 12.8mm High – 9mm Depth
- Ambient Temperature – -30 + 120C
- Housing – PBT
- Screw – M3 slotted
- UL File number E228872 – 14-22 Awg – 10A
- End-Stackable
